Custom Mixer Dredge
We design and manufacture custom dredge systems engineered around your project’s exact operational requirements — including flow rate, total dynamic head, solids concentration, particle size distribution, and site-specific conditions. Each unit integrates EDDY Pump’s non-clogging, high-solids slurry technology with purpose-built agitation, automation, and structural configurations to deliver maximum throughput, reduced wear, and reliable performance in abrasive, high-viscosity, or high-solids gain dredging applications.
Key Advantages of Custom Dredge Solutions
Engineered for High-Viscosity, High-Solids Applications
Custom dredging systems like The Egg Beater Dredge are specifically designed to handle materials that conventional dredges struggle with — including compacted muds, thixotropic slurries, and high specific gravity mixtures. Through powerful pre-agitation and mixing, the system liquefies dense materials before they reach the pump, ensuring a steady, uninterrupted flow and eliminating issues such as clogging or starvation.
Maximum Pumping Efficiency Without Boosters
The integrated pump-agitator-suction configuration enables the system to move thick, heavy material thousands of feet through discharge pipelines without additional booster pumps. This translates directly into reduced capital costs, simplified operations, and higher production rates in challenging dredging conditions.
Non-Clogging Performance and Consistent Production
At the core of every EDDY custom dredge is our patented pump technology — a unique design that leverages synchronized eddy currents to achieve superior solids handling and flow characteristics. Unlike centrifugal or positive displacement pumps, it maintains constant production even with high concentrations of abrasive, viscous, or corrosive materials.
Automation-Ready for Unmanned Operations
The Egg Beater Dredge can be fully integrated into autonomous dredging systems, enabling efficient large-area coverage with minimal labor. By anchoring cables to shore, the dredge can operate without an onboard crew, thereby reducing operational costs and enhancing safety in remote or hazardous environments.
Heavy-Duty Throughput and Production Capacity
Powered by HD Series EDDY Pumps, custom dredges deliver flow rates up to 4000 GPM and over 400 ft of head. This unmatched hydraulic performance allows operators to meet demanding throughput requirements while minimizing wear, downtime, and total ownership costs.
Proven, USA-Built Reliability
Since 1984, EDDY Pump has been a leader in innovation in dredging technology. Our custom systems are field-tested and engineered for long-term reliability in abrasive, high-solids, and chemically aggressive environments — making them the preferred choice for operators seeking maximum ROI and minimal maintenance.
Technical Specifications
Specs at a Glance
- Max Flow Rate: Up to 4,000 GPM (15,140 L/min)
- Total Dynamic Head: Over 400 ft (122 m) without booster pumps
- Solids Handling: >40% by weight with high viscosity and thixotropic materials
- Pump Sizes: 1″ – 12″ HD Series EDDY Pumps
- Agitation System: Dual “Egg Beater” agitators for continuous, clog-free production
Performance Specifications
- Flow Rate: Up to 4,000 GPM (15,140 L/min) depending on pump size and system configuration
- Total Dynamic Head (TDH): Capable of exceeding 400 ft (122 m) without booster assistance
- Solids Handling: Pumps high-concentration slurries with solids content > 40% by weight
- Viscosity Range: Optimized for highly viscous and thixotropic materials (e.g., compacted mud, sediment slurry)
- Discharge Distance: Thousands of feet through discharge pipelines without auxiliary pumps
Pump & Agitation System
- Pump Sizes Available: 1″, 2″, 3″, 4″, 6″, 8″, 10″, and 12″ HD Series EDDY Pumps
- Pump Type: Patented non-clogging EDDY Pump — not centrifugal, vortex, or positive displacement
- Agitation System: Dual “Egg Beater” agitators for pre-mixing, liquefying, and fluidizing material before pumping
- Production Stability: Consistent suction flow with minimal clogging or cavitation
Structural & Mechanical Specifications
- Mounting Options: Cable-deployed, pontoon-mounted, or integrated into automated dredge platforms
- Construction Materials: Heavy-duty, abrasion- and corrosion-resistant alloys suitable for harsh dredging environments
- Pipeline Compatibility: Works with standard dredge discharge lines; supports extended-distance slurry transport
- Automation Integration: Fully compatible with autonomous dredge control systems and remote operation packages
Application-Specific Capabilities
- Material Types: High-density mud, sludge, sargassum, tailings, contaminated sediments, industrial waste slurries
- Operating Environments: Rivers, lagoons, mining basins, wastewater treatment ponds, and coastal restoration sites
- Custom Engineering: System can be tailored for particle size distribution (PSD), solids SG, viscosity, and flow requirements
EDDY Pump – Custom Mixer Dredge
PUMP CURVE
A pump curve illustrates how the system delivers flow at varying head levels, helping verify performance under dense, abrasive slurry conditions. For the Custom Mixer Dredge, selecting the correct curve ensures stable throughput, efficient transport of high-solids material, and reliable operation over long discharge distances and in heavy-duty dredging environments.
Where Custom Dredges Deliver Results
Custom dredging solutions, such as The Egg Beater Dredge, are designed to perform in environments where conventional systems fail — delivering consistent flow, high solids handling, and reliable production across a wide range of heavy-duty applications. Here’s where these systems make the greatest impact:
Mining & Mineral Processing
Designed to handle abrasive tailings, slurry, and high-specific-gravity ore residues, custom dredges excel in mine pond cleanup, tailings dam management, and the transportation of dense mineral suspensions over long distances without the need for booster pumps. Their durability and throughput help reduce downtime and improve recovery efficiency.
Wastewater Treatment
Facilities processing thick sludge, biosolids, or grit-laden wastewater benefit from the dredge’s ability to maintain stable flow rates and prevent clogging, even with high-viscosity or fibrous materials. This ensures reliable operation during lagoon cleaning, digester maintenance, and solids handling tasks.
Marine Construction & Coastal Restoration
From dredging navigation channels and harbors to reclaiming land and rebuilding shorelines, the system’s robust pumping and agitation capabilities enable efficient handling of consolidated sediments, silt, and organic debris — critical for large-scale marine infrastructure and coastal protection projects.
Oil, Gas & Petrochemical
The dredge’s corrosion-resistant construction and non-clogging performance make it ideal for handling heavy drilling muds, refinery byproducts, and contaminated sediments. Operators can manage viscous slurries and hazardous residues safely while minimizing manual intervention and downtime.
Environmental Remediation
Whether removing contaminated sediments from industrial sites or clearing sargassum and organic buildup from coastal zones, custom dredges provide precise, continuous removal with minimal environmental disturbance — essential for cleanup, restoration, and compliance projects.
Agriculture & Pulp Processing
In lagoons, retention ponds, and biomass processing facilities, the dredge efficiently pumps slurry with high fiber content or organic load. Its ability to handle variable viscosity and solids content ensures consistent performance in applications like manure lagoon cleaning, pulp waste removal, and fertilizer slurry transport.
Autonomous Sargassum Harvesting and Disposal for Coastal Restoration
Case Study
The Challenge
A coastal restoration project in the Gulf region was facing severe operational and environmental setbacks due to massive seasonal sargassum accumulation. The thick, fibrous mats blocked water flow, disrupted marine habitat, and impeded navigation near shorelines. Manual removal methods were labor-intensive, costly, and inconsistent, often requiring large crews and frequent interruptions due to equipment clogging and limited pumping capacity.
The Solution
To overcome these challenges, EDDY Pump deployed a custom Egg Beater Dredge configured for fully autonomous, cable-anchored operation. The dredge’s twin agitators aggressively mixed the dense organic material into a pumpable slurry. At the same time, the high-solids HD series pump transported the mixture directly through extended discharge pipelines without the need for booster stations. Remote monitoring and automated positioning enabled the system to continuously dredge a wide operational area without requiring onboard personnel.
The Result
The autonomous dredging system successfully removed over 300 tons of sargassum within a two-week window, restoring navigable waterways and improving water quality ahead of schedule. Operational costs were reduced by more than 60% due to minimal labor requirements and reduced equipment downtime. The project demonstrated the effectiveness of the Egg Beater Dredge in large-scale coastal maintenance operations, setting a new benchmark for environmentally responsible and cost-efficient sargassum management.
Call for sales or support
If you need assistance with pump selection, sales or engineering support, call 619-404-1916.
Talk To About Any Question?
Frequently Asked Questions
What types of materials can the Egg Beater Dredge handle?
The custom mixer dredge is engineered to process highly viscous, thixotropic, and abrasive materials — including compacted mud, sludge, sargassum, tailings, and industrial slurry with high solids content. Its dual agitators pre-liquefy the material, enabling consistent flow without clogging, even in high-specific-gravity or fibrous applications.
How does the dredge mixer system differ from conventional dredging systems?
Unlike centrifugal or cutterhead dredges, the custom mixer dredge system integrates pre-agitation and a patented EDDY Pump to handle high-solids, high-viscosity material without losing suction or requiring frequent maintenance. It eliminates the need for booster pumps over long discharge distances and maintains steady production rates in challenging conditions.
Can the portable dredge mixer be customized to meet project-specific requirements?
Yes. Every custom dredge is engineered to match your operational parameters — including flow rate, TDH, solids concentration, particle size distribution, and site-specific conditions. We offer a range of pump sizes (1” to 12”), mounting options, automation levels, and materials of construction to meet your exact requirements.
What industries typically use the heavy-duty dredge mixer pump?
Our custom dredges are deployed across various industries, including mining, wastewater treatment, marine construction, oil and gas, environmental remediation, and agriculture. They are particularly effective in applications where conventional dredges struggle — such as tailings pond management, sludge lagoon cleaning, coastal restoration, and biomass slurry handling.
How far can the dredge pump transport material without a booster pump?
Thanks to the high-efficiency EDDY Pump and optimized agitation system, the industrial dredge mixer can transport dense slurry thousands of feet through discharge pipelines without requiring a booster pump, reducing system complexity and lowering operating costs.
Can the heavy-duty dredge mixer pump operate autonomously?
Yes. The system can be configured for fully automated, unmanned dredging by anchoring 3–4 cables on land and integrating remote monitoring and control packages. This allows large-area dredging operations without an onboard crew, improving safety and reducing labor costs.
What maintenance requirements should we expect?
Maintenance needs are significantly lower than traditional dredging systems. The non-clogging pump design and heavy-duty construction minimize wear and downtime, ensuring optimal performance. Routine checks typically include inspection of wear components, agitator condition, and pump seals, all of which are designed for extended service intervals.
What is the maximum flow rate and head the custom-built dredge can achieve?
Depending on configuration, the custom mixer dredge can deliver up to 4,000 GPM and exceed 400 ft of head without additional boosters. These capabilities allow efficient transport of abrasive and high-viscosity materials over extended distances.
Is the slurry agitation dredge compatible with existing infrastructure and pipeline systems?
Yes. Our systems are designed for seamless integration with standard discharge lines and site infrastructure. They can also be adapted to specific pipeline sizes, material transfer systems, and existing power or control platforms, thereby reducing installation time and costs.
What support and services are available after purchase?
EDDY Pump provides comprehensive lifecycle support, including engineering consultation, installation assistance, training, maintenance programs, and parts supply. We also offer remote diagnostics and field service to ensure your dredge operates at peak performance throughout its service life.
